Fire Hydrant Systems & Pump Rooms
HFC India Pvt Ltd delivers end-to-end industrial firefighting networks across Haryana. From heavy-duty MS C-Class ring-main loops to automated pump rooms, we guarantee 100% Fire NOC approval and 24/7 high-pressure reliability.
Industrial Grade Fire Hydrant Systems
A primary heavy-duty firefighting infrastructure designed to deliver immediate, continuous, and high-volume pressurized water streams across commercial and industrial facilities.
Continuous Water Supply
Directly connected to high-capacity underground storage reservoirs, ensuring an uninterrupted flow of water during extensive firefighting operations.
High System Pressure
Maintains 7.0 to 10.5 kg/cm² operating line pressure to propel water jets to multi-story heights and far-reaching outdoor areas.
NBC & TAC Compliant
Fully standard-aligned with National Building Code (NBC Part 4) and Bureau of Indian Standards (IS 13039) for government NOC approvals.
How the Hydrant Network Works
An automated pressure-monitored loop network designed for immediate response without manual valve priming delays.
Static Water Reservoir
Dedicated underground and overhead fire water storage tanks maintained exclusively for firefighting usage.
Automated Pump Room
Main Electric Pump, Standby Diesel Pump, and Jockey Pump keep line pressure locked at optimum operating levels.
Ring-Main Loop Piping
Heavy MS C-Class pipes encircle the premise, feeding all yard hydrants and internal landing valves.
Rapid Discharge
Connecting canvas hoses to landing valves unleashes controlled high-pressure streams directly at the target fire source.
Automated Auto-Start Sensing
When line pressure drops below 5.5 kg/cm², the Jockey Pump activates automatically. Opening a hydrant valve triggers the Main Electric or Diesel Pump instantly.
How a Fire Hydrant System Operates
A pressurized water ring-main network engineered to provide instant continuous high-pressure water supply during emergencies.
Static Water Reservoir
Dedicated underground and overhead fire water storage tanks maintained exclusively for firefighting usage as per NBC capacity standards.
Automated Pump Room
Main Electric Pump, Standby Diesel Pump, and Jockey Pump maintain continuous 7.0 kg/cm² pressure in the ring header network.
Ring-Main Loop Piping
Heavy MS C-Class pipes encircle the entire facility, supplying pressurized water to all yard hydrants and indoor landing valves.
Rapid Water Discharge
Connecting flexible canvas hoses to 63mm landing valves allows firefighters to discharge targeted high-pressure water jets directly at the fire.
Automatic Pressure Switch Logic
When line pressure drops below 5.5 kg/cm², the Jockey Pump activates automatically. Opening a hydrant valve triggers the Main Electric or Diesel Pump instantly.
Step-by-Step Installation & Testing Process
How HFC India Pvt Ltd executes turnkey Fire Hydrant projects from initial layout design to hydrostatic testing and statutory Fire NOC handover.
Site Survey & Hydraulic Layout
Calculating water flow requirement, mapping ring-main loop paths, and finalizing pump capacity as per National Building Code (NBC) norms.
Civil Works & Underground Piping
Trenching, laying anti-corrosive wrapped MS C-Class pipes underground, and constructing dedicated fire pump room & water reservoir foundations.
Pump Room Erection & Panel Wiring
Installing Main Electric Pump, Standby Diesel Pump, Jockey Pump, and integrating auto-start electrical control panels with pressure switches.
Yard Hydrants & Hose Cabinets
Installing 63mm gunmetal landing valves, swiveling hose reel drums, and glass-front MS cabinets stocked with canvas hose pipes.
Hydrostatic Pressure Testing
Testing the complete pipeline network at 10.5 Bar pressure for 24 hours to ensure 100% leak-free joints and structural integrity.
Commissioning & Fire NOC Audit
Full system live testing, operational training for site personnel, and providing compliance documentation for Fire Department NOC approval.
Hydrant Maintenance & Expert Consultation
Routine pressure audits, pump room servicing, and end-to-end turnkey fire protection services across Palwal, Faridabad, and Industrial Haryana.
Annual Maintenance Contracts (AMC)
Regular monthly functional tests of Diesel and Electric main pumps, line flushing, pressure switch calibration, and valve re-packing.
Fire NOC Audit & Fitness Reports
Comprehensive hydrostatic pressure testing and water flow measurements required for submission during state Fire Department NOC renewals.
Retrofitting & Pipeline Repairs
Replacing legacy underground pipelines, upgrading corroded fittings, and integrating modern automated pump room controllers.
